Osmond PCB by J Chavez

A Printed Circuit Board layout program with the following features.
  • Virtually unlimited board sizes
  • Virtually unlimited number of board layers
  • Virtually unlimited number of parts
  • Spatial resolution down to 10 nanometer
  • Concurrent support for both Imperial and Metric units
  • All angle routing
  • Rubber-band traces
  • Rats Nest Layer
  • Variable size grid
  • Support for both through-hole and surface mount parts
  • Circular, rectangular, and oval pads
  • Easy part editing
  • Variable trace widths
  • Variable trace spacing
  • Curved traces
  • Silkscreen, solder-mask, and auxiliary layers
  • Signal and ground planes
  • Copper fill areas
  • Automatic clearance checks
  • Easy manual and semi-automatic routing
  • Built-in script language
  • Gerber (RS-274X) and drill file (Excellon) output
  • DXF file output
  • DXF file input
  • Encapsulated PostScript file output
  • Net check output (IPC-356)



At the time of writing (April 10, 2000) "Osmond PCB" is in Beta version and is available FREE for download and testing at the web site:

http://www.swcp.com/~jchavez/osmond.html

Download should take less than 8 minutes.
